| Working Area | 1300x900mm |
|---|---|
| Laser Power | 60w 80w 100w 130w 150w |
| Laser Supply | Sealed Co2 Laser Tube EFR/CDWG/RECI |
| Engraving Speed | 0-1000mm/s |
| Cutting Speed | 0-300mm/s |
| Min Engraving Size | Chinese ：2*2mm，English：1*1mm |
Location Accuracy | ≥±0.01mm |
| Motherboard | DSP RuiDa or Trocen |
| Software | RDworks CorelDRAW CAD Photoshop |
| Graphic format | AI / PLT/ CDR / DXF / BMP / JPG / PNG etc. |
Operating Voltage | AC 110V - 220V ± 10% 50-60 Hz |
| Upgrade function | Double head / Rotary / CCD / Auto focus |
1300x900mm, industrial mechanical structure, high precision transmission, high processing efficiency, good abrasion resistance and long service life
Equipped with electric lifting platform, red light indicating positioning, air pump blowing
DSP operating system, can work offline, store 256 files, read U disk files
Upgradeable dual laser head, auto focus, CCD camera edge search and cutting
● Open design, the front of the machine can be extended, longer plates can be processed, industrial laser head, better engraving effect
Equipped with electric lifting platform, red light indicating positioning, air pump blowing
Applications：
